MOW1001

EPSON VX7R – multifunctional movement

Movement : quartz

Functions : 3 hands (hours, minutes, seconds), date, 24 hours

Display :

Crown surgery:

Set time :

(1) Pull the crown out to position 2 when the seconds hand is at the 12 o'clock position.
(2) Turn the crown clockwise to set the hour and minute hands.
minute hands.
*The 24-hour hand moves according to the hour hand.
*When setting the hour hand, check that the 24-hour hand is set correctly.
*When setting the minute hand, advance it 4 to 5 minutes ahead of the desired time and then set it back to the exact time.
reset to the correct time.
*When setting the hour and minute hands, take AM/PM into account.
(3) Once the time has been set, push the crown to position 0 to operate the seconds hand.
seconds hand.

Set date :

(1) Pull crown out to position 1.
(2) Turn the crown anti-clockwise to set the date hand.
date hand.
*Do not set the date between 9pm and 1am. Otherwise, it may not set correctly.
*The date hand will not move backwards when turning the crown clockwise.
(3) Once the date has been set, push the crown back to position 0.
